# Writing technical content in Markdown

Wowchemy is designed to give technical content creators a seamless experience. You can focus on the content and Wowchemy handles the rest.

**Highlight your code snippets, take notes on math classes, and draw diagrams from textual representation.**

On this page, you’ll find some examples of the types of technical content that can be rendered with Wowchemy.

## Examples

### Code

Wowchemy supports a Markdown extension for highlighting code syntax. You can enable this feature by toggling the `syntax_highlighter`

option in your `config/_default/params.toml`

file.

```
```python
import pandas as pd
data = pd.read_csv("data.csv")
data.head()
```
```

renders as

```
import pandas as pd
data = pd.read_csv("data.csv")
data.head()
```

### Charts

Wowchemy supports the popular Plotly format for interactive charts.

Save your Plotly JSON in your page folder, for example `line-chart.json`

, and then add the `{{< chart data="line-chart" >}}`

shortcode where you would like the chart to appear.

Demo:

You might also find the Plotly JSON Editor useful.

### Math

Wowchemy supports a Markdown extension for $\LaTeX$ math. You can enable this feature by toggling the `math`

option in your `config/_default/params.yaml`

file.

To render *inline* or *block* math, wrap your LaTeX math with `{{< math >}}$...${{< /math >}}`

or `{{< math >}}$$...$${{< /math >}}`

, respectively. (We wrap the LaTeX math in the Wowchemy *math* shortcode to prevent Hugo rendering our math as Markdown. The *math* shortcode is new in v5.5-dev.)

Example **math block**:

```
{{< math >}}
$$
\gamma_{n} = \frac{ \left | \left (\mathbf x_{n} - \mathbf x_{n-1} \right )^T \left [\nabla F (\mathbf x_{n}) - \nabla F (\mathbf x_{n-1}) \right ] \right |}{\left \|\nabla F(\mathbf{x}_{n}) - \nabla F(\mathbf{x}_{n-1}) \right \|^2}
$$
{{< /math >}}
```

renders as

$$\gamma_{n} = \frac{ \left | \left (\mathbf x_{n} - \mathbf x_{n-1} \right )^T \left [\nabla F (\mathbf x_{n}) - \nabla F (\mathbf x_{n-1}) \right ] \right |}{\left \|\nabla F(\mathbf{x}_{n}) - \nabla F(\mathbf{x}_{n-1}) \right \|^2}$$Example **inline math** `{{< math >}}$\nabla F(\mathbf{x}_{n})${{< /math >}}`

renders as $\nabla F(\mathbf{x}_{n})$.

Example **multi-line math** using the math linebreak (`\\`

):

```
{{< math >}}
$$f(k;p_{0}^{*}) = \begin{cases}p_{0}^{*} & \text{if }k=1, \\
1-p_{0}^{*} & \text{if }k=0.\end{cases}$$
{{< /math >}}
```

renders as

$$ f(k;p_{0}^{*}) = \begin{cases}p_{0}^{*} & \text{if }k=1, \\ 1-p_{0}^{*} & \text{if }k=0.\end{cases} $$### Diagrams

Wowchemy supports a Markdown extension for diagrams. You can enable this feature by toggling the `diagram`

option in your `config/_default/params.toml`

file or by adding `diagram: true`

to your page front matter.

An example **flowchart**:

```
```mermaid
graph TD
A[Hard] -->|Text| B(Round)
B --> C{Decision}
C -->|One| D[Result 1]
C -->|Two| E[Result 2]
```
```

renders as

An example **sequence diagram**:

```
```mermaid
sequenceDiagram
Alice->>John: Hello John, how are you?
loop Healthcheck
John->>John: Fight against hypochondria
end
Note right of John: Rational thoughts!
John-->>Alice: Great!
John->>Bob: How about you?
Bob-->>John: Jolly good!
```
```

renders as

An example **Gantt diagram**:

```
```mermaid
gantt
section Section
Completed :done, des1, 2014-01-06,2014-01-08
Active :active, des2, 2014-01-07, 3d
Parallel 1 : des3, after des1, 1d
Parallel 2 : des4, after des1, 1d
Parallel 3 : des5, after des3, 1d
Parallel 4 : des6, after des4, 1d
```
```

renders as

An example **class diagram**:

```
```mermaid
classDiagram
Class01 <|-- AveryLongClass : Cool
Class03 *-- Class04
Class05 o-- Class06
Class07 .. Class08
Class09 --> C2 : Where am i?
Class09 --* C3
Class09 --|> Class07
Class07 : equals()
Class07 : Object[] elementData
Class01 : size()
Class01 : int chimp
Class01 : int gorilla
Class08 <--> C2: Cool label
```
```

renders as

An example **state diagram**:

```
```mermaid
stateDiagram
[*] --> Still
Still --> [*]
Still --> Moving
Moving --> Still
Moving --> Crash
Crash --> [*]
```
```

renders as

### Todo lists

You can even write your todo lists in Markdown too:

```
- [x] Write math example
- [x] Write diagram example
- [ ] Do something else
```

renders as

- Write math example
- Write diagram example

- Do something else

### Tables

Save your spreadsheet as a CSV file in your page’s folder and then render it by adding the *Table* shortcode to your page:

```
{{< table path="results.csv" header="true" caption="Table 1: My results" >}}
```

renders as

customer_id | score |
---|---|

1 | 0 |

2 | 0.5 |

3 | 1 |

### Callouts

Academic supports a shortcode for callouts, also referred to as *asides*, *hints*, or *alerts*. By wrapping a paragraph in `{{% callout note %}} ... {{% /callout %}}`

, it will render as an aside.

```
{{% callout note %}}
A Markdown aside is useful for displaying notices, hints, or definitions to your readers.
{{% /callout %}}
```

renders as

### Spoilers

Add a spoiler to a page to reveal text, such as an answer to a question, after a button is clicked.

```
{{< spoiler text="Click to view the spoiler" >}}
You found me!
{{< /spoiler >}}
```

renders as

## Click to view the spoiler

You found me!

### Icons

Academic enables you to use a wide range of icons from *Font Awesome* and *Academicons* in addition to emojis.

Here are some examples using the `icon`

shortcode to render icons:

```
{{< icon name="terminal" pack="fas" >}} Terminal
{{< icon name="python" pack="fab" >}} Python
{{< icon name="r-project" pack="fab" >}} R
```

renders as

Terminal

Python

R
